Lightweight 6061
Alloy Frame
Carbon
Composite Fork
Tektro
hydraulic brakes
18-Speed (2x9)
Shimano Drivetrain
Lightweight 6061 Alloy Frame
Go faster for less effort with a stiff, lightweight alloy frame.
Carbon Composite Fork
Gain the competitive edge with a premium carbon composite fork. Carbon is the material of choice for cyclists who wants to maximise their performance. Being lighter than steel, this fork helps boost your speed and acceleration while reducing unwanted vibrations.
Shimano 18-Speed Drivetrain
The 18-Speed (2x9) Shimano drivetrain provides smooth and reliable gear shifting that will allow you to adapt to any incline.
Strong Stopping Power
Experience smooth and consistent braking with the Tektro hydraulic brakes. These high-performance brakes are reliable and built to last.
The Blueprints
An awesome package with the following components:
- A. Lightweight 6061 Alloy Frame
- B. Carbon Composite Fork
- C. Tektro Hydraulic Brakes
- D. Shimano 18-Speed Drivetrain
- E. Touring Saddle with SL Cover
- F. Double Wall Alloy Rims
Where to ride?
Specification
Technical Specifications
| Frame | Size Specific Design Triple-butted 6061 alloy with fast back rear triangle, internal cable routing, formed top and down tube, oval chain stays with flat mount disc brake, kickstand mount, replaceable derailleur hanger and fender/ rack eyelets |
|---|---|
| Fork | full carbon composite with carbon steerer, Flat mount disc brake, low-rider carrier mounts and carbon drop out with stainless steel tabs and fender eyelets |
| Headset | FSA Integrated IS threadless with nylon upper compression ring, 1 1/8” |
| Wheels | Alex TD26 double wall disc specific alloy rims, 32H, Joytec 6-bolt alloy hubs with QR and 14g stainless steel spokes |
| Tires | Vittoria Randonneur with reflective sidewalls, 700 x 35c |
| Derailleurs | Shimano Altus RD-M2000 rear and Shimano Altus FD- M370 front derailleur |
| Shift levers | Shimano Rapidfire Plus Altus SL-M2010, 18-speed |
| Chain | KMC Z9 |
| Cassette | Shimano HG200 9-speed, 11-34T |
| Crankset | Shimano FC-MT210, 46/30, 170mm (15-19”), 175mm (21-23”). |
| BB Set | FSA sealed cartridge, 68 x 110.5mm |
| Pedals | Platform style, steel cage/resin body |
|---|---|
| Brakeset | Tektro HD-M280/281 hydraulic Flat Mount disc brakes with 160mm rotors and Tektro brake levers. 15-17” M281 (83mm reach); 19-23” M280 (88mm reach) |
| Handlebar | Flat bar, 6061 T-6 alloy, 31.8 x 10 ̊ sweep x 600mm (15-17”) 620mm (19-23”) |
| Stem | Road 3D forged alloy, 10 ̊ rise x 90mm (15/17”), 105mm (19/21”), 115mm (23”) |
| Grips | Anatomic double density kraton |
| Seat Post | Alloy micro-adjust, 27.2 x 350mm alloy clamp with QR seatpin |
| Saddle | Touring with SL cover |
| Sizes | 17”, 19”, 21” |
| Color | Grey |
| Weight | Approx. 11.7kg |
Bike Size Guide
| Frame Size Number | 17" | 19" | 21" |
| Wheel Size | 26" | 26" | 26" |
| A - Seat Tube Angle | 73° | 73° | 73° |
| B - Head Tube Length | 14.5cm | 17cm | 19cm |
| C - Effective Tube Top | 56.6cm | 57.7cm | 58.9cm |
| D - Chainstay Length | 43.5cm | 43.5cm | 44cm |
| E - Wheelbase | 103.9cm | 105.2cm | 105.9cm |
| F - Standover | 76.6cm | 80.4cm | 83.9cm |
